Chemineer agitators

Chemineer Mixing technology

Chemineer offers a broad variety range of turbine mixers static mixers and agitators, suitable for almost all processes demanding for fluid or gas agitation.

Agitators provide a performance of 0,18kW-1,000kW with speeds from and speeds from 4-1,500/min. Greerco rotor-stator mixer / colloid mills perform from 1.5kW- 15kW.

Description

Technology: Chemineer agitators and Kenics Static mixers offer all the technologies around the topic of mixing in tanks, pipes or heat exchangers. Rotor-stator mixers and colloid mills are also available.

Advantages:

  • Large selection of paddles
  • Vertical and horizontal standard agitators
  • Stainless steel mixers for industrial, food and pharmaceutical industries
  • Tank Installation in closed and open containers
  • ATEX Zone 1 and Zone 0
  • Drive power up to 1,000 kW
  • Multilevel shear mixing systems for all applications

Options

  • Materials from 316L stainless steel to Hastelloy
  • Sealing by single or double mechanical seal
  • Possible up to 40 bar
  • Manufactured for food / pharma with Tri-Clamp, CIP capable
  • Pharma design ASME 2002BPE
  • Belt drives

Technical data

Mixer series  Power in [kW] Speed range in [rpm] Design
MR229 - 230Gear motor
GT309 - 125Gear motor
HS55190 - 290Gear motor
HT1,0004 - 230Gear motor
DT4100 - 1,500Direct drive or gear motor
XP0.75900 - 3,000Direct drive with bunghole assembly clamp

Rotor/stator mixer Flow rate in [l/min] Discharge pressure in [bar] Shear rates in [/sec.]
vPLM/SPLM40 - 1,0001060,000
Colloid mill W10 - 300394,000 - 130,000

Static mixersTechnical description
Series KM
  • Homogenization of low to moderately viscous fluids, gas compounds
  • Gentle homogenization
  • Temperature homogenization

Series HEV
  • Mixing of turbulent flows
  • Intensive cross-flows
  • Counterrotating vortices
Series KMX
  • Mixing grids generate contrary radial flows
  • High shear
  • Short overall length
Heat exchanger
  • Optimized heat exchange between the pipe wall and medium by helical inserts.
  • Temperature control through perfect homogenization
